Multipass3.wav - Wav file for Leeloo's voice MultiPass_Version2.fzz - Parts drawing and connectivity MultipassV2_Demo.mov - This shows some of the features of the multipass version 2 Or another program of your choosing.įor the X-ray picture, Copy your original picture and use PS to ‘invert’ the image under ‘Image, ‘Adjustments’ the ‘Invert’ menu. The size of the pictures can be done in Photoshop (PS) menu: ‘Image’, ‘Image Size’. You will have to change the following because in order to get to ‘Fhloston Paradise’ duplicate IDs are highly unacceptable:
#Multipass vaccine card movie#
You can use a solid color option ( ) the choice is yours. Wire Wrap ( ) I used multiple colors to keep my wiring sanity. I chose a higher value to try and reduce brightness Metal Ball Tactile Button ( ) This is the pushbutton for the night light.ģmm LED ( ) You can use any type/color of 3mm LEDĭiode Used to connect between powerboats 5V and 5V pin of QT Py 2040 (see above)Ģ.2K Resistor You can use your own value of resistor. If you choose to use a different button, hot glue is your friend, or 3D print some to Cathode side to 5V pin of QT Py ( ) Cathodeħ Jewel Neopixel ( ) This goes into the lens disc holeĪdafruit LED Sequins - Emerald Green, Pack of 5 (these are 3 of the lights I used for the rod and the night light) Powerboost ( ) or if you have a different type of LiPo charger, you can use that.ĭiode - Used a diode to connect to 5 volt pin of the QT Py 2040. I put a dab of hot glue for theīattery since it will be recharged by the power boost.Ĥ20 mAh LiPo ( ) You can use a smaller size, Its just what I had at the time. Unlike version 1, I did not make a battery holder for this version. You can use any size lips battery you like.In this version 2, I made the stem/rod slightly longer due to the slight change in the button geometry. The parts are small so the cuts are fast and simple. A light diffusion 3D material can be used. The power led was to the left to allow the pass card to not be notched.Įxtra holes were added in the bottom part for wiring.Ĭavities were added for the three sequin ledsĪcylic does not have to be used. (This depends on the type of switch you use) The geometry around the on/off button was slightly widen. Remix of a remix of a remix of a remix and on and on. 3D PRINTING MODIFICATION FROM VERSION 1:Īs mentioned before, version 1 is a re-mix of the Ruiz brothers from a remix from a user ‘Level2three’. The bottom part as this could prevent the card from sliding in all the way to the back.
And just a small bead on the bottom of the QT Py 2040. To insure connectivity, I also soldered the connections of the wire-wrap. To try and keep a thin profile, I used wire-wrap.
#Multipass vaccine card code#
Also in the code ignore the two lines 'button'. The code file ‘Multipass_V2.py’ has to be changed to ‘code.py’ for the QT Py 2040. THIS PROJECT USES CIRCUITPYTHON 6.3.0 VERSION BELOW ARE THE NOTES FOR HOW EVERYTHING WAS USED AND METHODS TO CREATE THE MULTIPASS V2. All files needed to create this project are included.
Refer to VERSION 1 because there are some things that are similar. This document contains all aspects to completing this project.
